 Creator C502 BENZ & OBDII/EOBD  Multi-system Scanner



Creator C502 BENZ software description



Supports all the BNEZ models before 2016

Include Chassis: 117, 129, 140, 156, 163, 164, 166, 168, 169, 170, 171, 172, 176, 197, 199, 202, 203, 204, 205, 207, 208, 209, 210,

                                211, 212, 215, 216, 217, 218, 219, 220, 221, 222, 230, 231, 240, 245, 246, 251, 253, 292, 461, 463, X 164, X 204

Functions: Read codes, Erase codes, ECU information



Creator C502 OBDII & EOBD software description:



 Works on all 2001 and later OBDII compliant PETROL European vehicles

 Works on all 2004 and later OBDII compliant DIESEL European vehicles

 Works on all 1996 and later OBDII compliant US and Asian vehicles

 Easily determines the cause of the "Check Engine Light ( MIL)"

 Retrieves generic (P0, P2, P3, and U0) and manufacturer specific (P1, P3,and U1) codes

 Turns off Check Engine Light (MIL), clears codes and resets monitors

 Displays DTC definitions on unit screen

 Views freeze frame data

 Identifies pending codes

 Reads live PCM datastream

 Graph displays live PCM datastream

 Read I/M Readiness Status

 Displays live O2 sensor test data

 Performs modules present test

 Retrieves vehicle information (VIN, CIN and CVN)

 Supports CAN (Controller Area Network) and all other current OBD-II protocols



Creator C502 Language Set Up:



Creator C502 Specifications:



A) Display: Color, 320 x 240 pixel display with contrast adjustment

B) Operation Temperature: - 20 ℃ -- 75 ℃

C) Storage Temperature:  -40 ℃  --  120 ℃

D) Power:  8V -- 24V



Product Troubleshooting

Vehicle Linking Error



A communication error occurs if the scan tool fails to communicate with the vehicle’s ECU (Engine Control Unit).

You need to do the following to check up:

A) Verify that the ignition is ON;

B) Check if the scan tool’s OBD II connector is securely connected to the vehicle’s DLC;

C) Verify that the vehicle is OBD2 compliant;

D) Turn the ignition off and wait for about 10 seconds. Turn the

E) Ignition back to on and continue the testing.

F) Verify the control module is not defective



Scan tool doesn’t power up

If the scan tool won’t power up or operates incorrectly in any other way, you need to do the following to check up:

A) Check if the scan tool’s OBD II connector is securely connected to the vehicle’s DLC;

B) Check if the DLC pins are bent or broken. Clean the DLC pins if necessary.

C) Check vehicle battery to make sure it is still good with at least 8.0 volts.



Package includes:



1pc x C502 machine

1pc x  User's Manual
